10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v

10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v
10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v
video play

Large Image :  10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v

Product Details:
Place of Origin: China
Brand Name: OKYSTAR
Certification: CE
Model Number: PQL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 2.23-7.5usd/pc
Packaging Details: Carton package
Delivery Time: 3-5 days
Payment Terms: L/C, Western Union, T/T, Western Union, MoneyGram
Supply Ability: 100000PCS/WEEKS
Detailed Product Description
Output Voltage: 28-42V Output Current: 130-250mA 250-350mA 350-450mA 450-600mA 700-1000mA 1250-1500mA 1000-1250mA
Name: LED Dimmable Driver Type: Constant Current
Environmental Protection: RoHS Power Factor: >0.9
High Light:

50w Dimmable LED Driver

,

40w Dimmable LED Driver

,

Constant Voltage Led Driver 24v

10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v



Triac Dimmable Led Driver High Voltage Flicker-Free Constant Current

NU SKU Specification Warranty
Output Power Input Voltage Output Voltage Output Current transfer efficiency PF Product
Size
(MM)
  PQL009 5-10W 200-240V 28-40V 130-250mA 88% >0.9 95*36*25 5years
PQL013 10-13W 200-240V 28-40V 250-350mA 88% >0.9 95*36*25 5years
PQL018 13-18W 200-240V 28-40V 350-450mA 88% >0.9 115*41*25 5years
PQL022 18-22W 200-240V 28-40V 450-600mA 88% >0.9 115*41*25 5years
PQL040 25-40W 200-240V 28-40V 700-1000mA 88% >0.9 135*45*29 5years
PQL050 40-50W 200-240V 28-40V 1250-1500mA 88% >0.9 135*45*29 5years
PQL060 40-50W 200-240V 28-40V 1000-1250mA 88% >0.9 156*50*38 5years


FEATURES

  •  180-264VAC input
  •  Class Ⅰdriver,with flicker
  •  Built in active PFC function,high PF,low THD
  •  Cooling by free air convecation
  •  Suitable for indoor LED lighting applications
  •  5 years warranty

APPLICATION

  •  LED indoor lighting
  •  LED office lighting
  •  LED architectural lighting
  •  LED commercial lighting



Feature



  •  Cooling by free air convecation
  •  Suitable for indoor LED lighting applications
  •  5 years warranty
  •

Parameters



  •  Input Voltage:100/200-240VAC
  •  Harmonic Current:<15%
  •  Working Temperature:-20~45℃
  •  Environmental Protection:RoHS
  •  EMI Emission:EN55015 GB17743 EN61000-3-3 EN61000-3-2 CLASS C
  •  Safety standard: EN61347-1,EN61347-2-13/GB19510-1,GB19510-2-14
  •  Power Factor:>0.9
  •  Protection:SCP/OCP/OVP/OTP
  •  Storage temperature:-40~80℃
  •  Life span:50000H&45℃ <MIL-HDBK-217F>
  •  Hi-pot: I/P-O/P:3750VAC
  •  EMS Interference:EN61547 EN61000-4-2,3,4,5,6,8,11

10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v 0

10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v 1

10W 40W 50w Dimmable LED Driver Constant Voltage Led Driver 24v 2



Our Services:

1. 3-5 working days for samples; 7-10 working days for bulk orders normally.
2. Powerful R&D team, can provide good designs and lighting solutions.
3. Quick and high efficiency after-sale team, your complaints will be solved with 24 hours by professional team.
4. We supply OEM and ODM service, and only focus on high quality products.
5. Payment terms : L/C, Western Union, T/T.
