2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w

2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w
2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w
video play

Large Image :  2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w

Product Details:
Place of Origin: China
Brand Name: OKYSTAR
Certification: CE
Model Number: PUL-AD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 13.2-18.7usd/pc
Packaging Details: Carton package
Delivery Time: 3-5 days
Payment Terms: L/C, Western Union, T/T, Western Union, MoneyGram
Supply Ability: 100000PCS/WEEKS
Detailed Product Description
Output Voltage: 3-42V Output Power: 10-30W 30-40W 50-60W
Output Current: 250-800mA 600-1100mA 800-2000mA Application: Led Lighting Products
Product Name: Led Driver For Dimming Light Type: DALI Dimmable Led Driver
High Light:

2000mA Dimmable Led Transformer

,

Rainproof Led Power Supply 12v 400w

,

12v 400w Dimmable Led Transformer

2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w



Led Dimmable Driver DALI2 PUSH 1-10V 3 In 1 Dimmer LED Drive Module



SKU Specification Warranty
Output Power Input Voltage Output Voltage Output Current transfer efficiency PF Product
Size
(MM)
PUL030AD 10-30W 200-240V 3-42V 250-700mA 88% >0.9 103*68*30 5years
PUL042AD 30-40W 200-240V 3-42V 600-1100mA 88% >0.9 103*68*30 5years
PUL060AD 50-60W 200-240V 3-42V 800-2000mA 88% >0.9 123*79*30 5years



Detailed


  •  Input Voltage 180-265VAC, withstand 380VAC high voltage short-time shock.
  •  Turn on delay time<0.5S, standby power consumption<0.5W.
  •  Output current could choose by end user through DIP switch.
  •  With SCP/OCP/OVP/OTP.
  •  Flick free and soft dimming at any brightness;could be closed.
  •  Achieve dimming synchronization effect in condition of any combination of lamps.
  •  Built in correction of the output current ± 1% accuracy.
  •  High efficiency, up to 90%, low THD<7%.
  •  Built in DALI dimming function.
  •  Passed ENEC,RCM,CCC,SAA,SUD-TUV certification.
  •  5 years warranty.



Feature



  •  Input Voltage 180-265VAC, withstand 380VAC high voltage short-time shock.
  •  Turn on delay time<0.5S, standby power consumption<0.5W.
  •  Output current could choose by end user through DIP switch.
  •  With SCP/OCP/OVP/OTP.
  •  Flick free and soft dimming at any brightness;could be closed.
  •  Achieve dimming synchronization effect in condition of any combination of lamps.
  •  Built in correction of the output current ± 1% accuracy.
  •  High efficiency, up to 90%, low THD<7%.
  •  Built in DALI dimming function.
  •  Buit-in IoT digital interface.
  •  Passed ENEC,RCM,CCC,SAA,SUD-TUV certification.
  •  5 years warranty.



Parameters



  •  Input Voltage:200-240VAC
  •  Harmonic Current:<7%
  •  Working Temperature:-20~45℃
  •  Environmental Protection:RoHS
  •  Dimmable Mode:DALI
  •  EMC Emisson:EN55015,GB17743,EN61000-3-2 Class C(≥50% load),EN61000-3-3
  •  Safety standard:EN61347-1/2-13,GB19510.1/14 EN62384
  •  Power Factor:>0.9
  •  Protection:SCP/OCP/OVP/OTP
  •  Storage temperature:-40~80℃
  •  Life span:50000H
  •  Hi-pot: I/P-O/P:3750VAC
  •  Electromagnetic Interference:EN61000-4-2,3,4,5,6,8,1,EN61547,surge:DM 2KV

2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w 0

2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w 1

2000mA Dimmable Led Transformer Rainproof Led Power Supply 12v 400w 2



Our Services:

1. 3-5 working days for samples; 7-10 working days for bulk orders normally.
2. Powerful R&D team, can provide good designs and lighting solutions.
3. Quick and high efficiency after-sale team, your complaints will be solved with 24 hours by professional team.
4. We supply OEM and ODM service, and only focus on high quality products.
5. Payment terms : L/C, Western Union, T/T.
