EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply

EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply
EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply
video play

Large Image :  EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply

Product Details:
Place of Origin: China
Brand Name: OKYSTAR
Certification: CE
Model Number: PPL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 5.75-11.25usd/pc
Packaging Details: Carton package
Delivery Time: 3-5 days
Payment Terms: L/C, Western Union, T/T, Western Union, MoneyGram
Supply Ability: 100000PCS/WEEKS
Detailed Product Description
Output Voltage: 30-40V(36V) Output Current: 300-600mA 700-1000mA 1050-1250mA 1300-1500mA
Name: LED Dimmable Driver Output Power: 12-22W 30-40W 40-50W 50-60W
Name: 1-10V Dimmable LED Driver Type: Dimming Led Driver
High Light:

EN 61347-1 Dimmable Led Driver

,

Dimmable Led Driver 50 Watt

,

EN 61347-1 Waterproof Power Supply

EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply



Triac Dimmable Led Driver High Voltage Flicker-Free Constant Current

NU SKU Specification Warranty
Output Power Input Voltage Output Voltage Output Current transfer efficiency PF Product
Size
(MM)
  PPL022 12-22W 200-240V 30-40V(36V) 300-600mA 88% >0.9 55*25.5 5years
PPL042 30-40W 200-240V 30-42V(40V) 700-1000mA 88% >0.9 138*45*32 5years
PPL050 40-50W 200-240V 30-42V(40V) 1050-1250mA 88% >0.9 138*45*32 5years
PPL060 50-60W 200-240V 30-42V(40V) 1300-1500mA 88% >0.9 162*51*36 5years

Detailed:

FEATURES

  •  Universal AC input / withstand 380VAC high voltage short-time shock.
  •  Built-in active PFC function
  •  Protection: SCP/OCP/OVP/OTP
  •  Cooling by free air convection
  •  Class II power unit: L N
  •  Suitable for indoor LED lighting applications
  •  3/5 years warranty, Flicker-Free
  •  Series power supply: 20W/34W/50W/60W
  •  Compliance to: TUV-CE,CB,SAA,RCM,CCC

APPLICATION

  •  Universal AC input / withstand 380VAC high voltage short-time shock.
  •  Built-in active PFC function
  •  Protection: SCP/OCP/OVP/OTP
  •  Cooling by free air convection
  •  Class II power unit: L N
  •  Suitable for indoor LED lighting applications
  •  3/5 years warranty, Flicker-Free
  •  Series power supply: 20W/34W/50W/60W
  •  Compliance to: TUV-CE,CB,SAA,RCM,CCC

Feature

  •  Constant currentmode output with mulitiple levels selectable
     by DIP.switch
  •  Cooling by free air convecation
  •  Supporting multi-power supplys synchronous dimming
     connected in parallel
  •  5 years warranty



Parameters

  •  Input Voltage:100/200-240VAC
  •  Harmonic Current:<15%
  •  Working Temperature:-20~45℃
  •  Environmental Protection:RoHS
  •  EMI Emission:EN55015 GB17743 EN61000-3-3 EN61000-3-2 CLASS C
  •  Safety standard: EN61347-1,EN61347-2-13/GB19510-1,GB19510-2-14
  •  Power Factor:>0.9
  •  Protection:SCP/OCP/OVP/OTP
  •  Storage temperature:-40~80℃
  •  Life span:50000H&45℃ <MIL-HDBK-217F>
  •  Hi-pot: I/P-O/P:3750VAC
  •  EMS Interference:EN61547 EN61000-4-2,3,4,5,6,8,11

EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply 0

EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply 1

EN 61347-1 50 Watt Dimmable LED Driver IP65 Waterproof Power Supply 2
