PWM 24 Volt Dimmable LED Driver For Led Strip Lights Power Supply

PWM 24 Volt Dimmable LED Driver For Led Strip Lights Power Supply
PWM 24 Volt Dimmable LED Driver For Led Strip Lights Power Supply
video play

Large Image :  PWM 24 Volt Dimmable LED Driver For Led Strip Lights Power Supply

Product Details:
Place of Origin: CHINA
Brand Name: OEM
Certification: CE, Rohs
Model Number: BK-DHL
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: 9.24-16.5USD
Packaging Details: standard packaging
Delivery Time: 4-6 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000PCS/WEEKS
Detailed Product Description
Output Power: 10-80w Output Current: 300-2000mA
Warranty: 5years Transfer Efficiency: 88%
Input Voltage: 220V Application: Led Lighting Products
High Light:

24 Volt Dimmable LED Driver

,

PWM Dimmable LED Driver

,

ODM Led Strip Lights Power Supply

PWM 24 Volt Dimmable LED Driver For Led Strip Lights Power Supply



Dimmable LED Driver PUSH/1-10V/PWM/ Dimming Resistance 4 In 1 EU Strip Light



Product Feature


PUSH/1-10V/PWM/ Dimming Resistance 4 in 1

PUSH/1-10V/PWM/ Dimming Resistance 4 in 1PUSH/1-10V/PWM/ Dimming Resistance 4 in 1
IP20 non-waterproof, indoor use or installed in a rainproof box.
Ultra thin fanless cooling design, no noise from fan.
100% full load burn-in test.
Protections: short circuit, over load, over voltage, over temp.
Dimming interface:PUSH/1-10V/PWM/ Dimming Resistance 4 in 1
Apply to leading edge / trailing edge Triac dimmers and 0-10vdimming system.
Built-in high performance MCU, dimming curve can be customized.
Dimming range: 0~100%, LED start at 0.1% possible .
Multi-current & wide voltage, suitable for different power LED.
Short circuit / Over-heat / Over load protection.
Class 2 power supply. Full protective plastic housing.
Compliant with Safety Extra Low Voltage standard.



Feature



A full control and dimming ability to your lights by adding in this driver, which uses the Digital Addressable Lighting Interface (DALI) standard . You will be

able to simply and easily control the exact light output from your lights dimming from 3% to 100% in a smooth step free way.





SKU Product Specification Warranty
Output Power Input Voltage Output Voltage Output Current transfer efficiency PF SIZE
BK-DHL030BP 10-30W 200-240V 6-54V 300-750mA 88% >0.9 245*30*21 5years
BK-DHL040BP 30-40W 200-240V 6-54V 550-1100mA 88% >0.9 285*30*21 5years
BK-DHL050BP 40-50W 200-240V 6-54V 800-1300mA 88% >0.9 245*30*21 5years
BK-DHL060BP 50-60W 200-240V 6-54V 1200-1650mA 88% >0.9 355*30*21 5years
BK-DHL080BP 60-80W 200-240V 6-42V 1300-2000mA 88% >0.9 355*30*23 5years



About DALI Dimmable



The driver applies DALI dimming module independently developed by our company, conforms to DALI communication protocol of international standard, The dimming range is 3-100%, 0 off, the dimming curve is optional for index or linear mode, brightness changes smoothly during dimming, and it has the function of lamp drop detection.
