Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System

Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System
Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System

Large Image :  Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System

Product Details:
Place of Origin: CHINA
Brand Name: Okystar
Model Number: DIN DALI
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: $188.00, Sample1-10pcs; $178.60, 11-100pcs; $172.96, 100-300pcs; $165.44, 300pcs-500pcs;
Packaging Details: Carton Package
Delivery Time: 3-5 Work Day
Payment Terms: T/T, Western Union
Supply Ability: ≥1000 pcs Per Day
Detailed Product Description
Input Voltage: DC24V Power Consumption: ≤10W
DALI Power Output: 250Ma Connect: USB\ RS-485
Operating Temperature: 0-70℃ Weight:: 300g
High Light:

lamp control module

,

automatic headlight control module

DALI Controller Supports RS-485 Ports Applied In Home Automation System



Description



Being the intelligent lighting international standard bus agreement, DALI is widely applied in indoor lighting. DALI bus can be connected with a maximum of 64 devices, including 16 groups and 16 scenes. It also has some function setting parameters which give DALI more application flexibility and meet the demands for different occasions more easily. There must be a DALI bus to set the parameters for DALI lamps, so Our company design the OKYSTAR DALI bus which has DALI Tools software, powerful functions and widely applied in illumination engineering and debugging.

I. Product Characteristics

With USB and RS-485 communication interface;
Support a DALI bus, most allow linking 64 DALI lighting equipment ;
Scan equipments, meet the requirement of automatic address assignment of DALI protocol;
There are 3 ways to assign address;
Broadcast equipments, control group or single address;
All the parameters of the parameters table of DALI protocol can be read or set;
Setting / reading by group;
Setting / reading by Scene;
With DALI POWER individual output interface, more flexible compatibility;
Provide third-party control commands and seamless integrated control with third-party control system;
Built-in 220V AC power input port and 24V DC input port, which can be operated by any of the power supply modes.

Main technical indexes

Input voltage
DC24V
power consumption
≤10W
DALI power output
250Ma
Connect
USB RS-485
Operating temperature

 0-70℃

Operating huminity
10%-90% RH(no-condensing)
Weight
300g

Product size and installation wiring

Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System 0

Mounting :

The DALI Master is made for DIN rail mounting (35 mm DIN rail), which can provide customer with a more convenient method for installation.
Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System 1

An application example for DALI Master:
Intelligent Dali Lighting Control Module RS-485 Ports Applied In Home Automation System 2


Different packing at optional:


1. Retailing Packing:
Neutral Carton Package

2. Bulking Packing:
Carton Package-Can save packing cost
Anti-static bag--Can protect electronic components from potential electrostatic hazards

3. Customized Packing
Can design and pack according to your requirement,such as colorful box,blister packing,sealed packing with your company information, bar code,ect. ( Discuss extral)



FAQ:



1. What is intelligent lighting control system?

A lighting control system is an intelligent network based lighting control solution that incorporates communication between various system inputs and outputs related to lighting control with the use of one or more central computing devices. Lighting control systems are widely used on both indoor and outdoor lighting of commercial, industrial, and residential spaces.



2. What is the advantage compare with the traditional lighting control?



Improve energy efficiency

Reduce maintenance cost

Easy operation and more convenient



3. What Okystar can supply for you?



Okystar can offer a whole solution of lighting control system for you, economic and customization, with industrial-grade design, product architecture in line with international electrical standards, using high-quality components, products are stable and reliable.
